Introduction

It connects DJI Ronin-S to specified S0NY cameras to control the camera

Lightweight and Durable, easy to carry and store

It may enable the stabilizerto control compatiblecameras to:

Capture photo

Start/stop recording video

Zoom control(digital or optical)

Trigger auto focus

Note: Above functions depends on the camera and stabilizer, not our cables.Only 'Capture photo'& 'Start/Stop Recording' functions works for some old cameras.

Specification

Color: Black

Material: PVC

Length: About 30 cm = 11.8 inch

One End: MCC=Multi-Camera Control (4 pin)

Another End:Multi-USB, also called S2 as popular abbr in photo field

Manufacturer: third-party, not original from DJI

How to use

1. Connect the cable to Camera and Stabilizer

2. Turn on the stabilizer and select specified camera in the setting

3. Switch on the camera

4. If not work, adjust to M mode, then shut down the camera and re-start the camera, press the RED button to start recording, it should work.

Suitable for

DJI Ronin-Sstabilizer only

Most of S0NY cameras with Multi USB port, such as A9, A7R IV, A7R III, A7 III, A7 II, A7S II, A7S III, A6600, A6500, etc.

Note:

1.The optical zoom can be controlled through the Ronin-S Focus Wheel (only lenses with built-in power zoom, such as the E PZ 18-105 mm F4 G OSS). If a non-Power Zoom lens is mounted, the Focus Wheel will control digital zoom. Digital zoom must be enabled in your camera’s settings.

2.After connecting with a S0NY camera using the MCC-Multi cable, if you need to swap to a camera of other manufacturers then a gimbal reboot is required.

3. No <Pull focus electronically> and <Power up the Camera> for A7S III

Package Include

1 X Control Cable
